4,6 m Tyre rack RR2000 / 40 cm deep / 2 m high / 3 levels
- Easy storage of complete tyres or individual rims
- Straightforward assembly with just a few steps
- High flexibility and expandability of the tyre rack
- Other rack types, such as shelving with sloping floors and warehouse racks, can be integrated
- High bay loads of 2.000 kg
- Easy storage of complete tyres or individual rims
- Straightforward assembly with just a few steps
- High flexibility and expandability of the tyre rack
- Other rack types, such as shelving with sloping floors and warehouse racks, can be integrated
- High bay loads of 2.000 kg
-
ModelRR2000
-
Number of levels3
-
Rack layerWithout
-
Width4,600 mm
-
Depth400 mm
-
Height2,000 mm
-
Max. load per field2,000 kg
-
Maximum load per level400 kg
- 3 x tyre rack upright 2 m high / 40 cm deep, unit load capacity: 2.000 kg
- 12 x tyre rack beams 220 cm wide, compartment load capacity: 400 kg
- All material required for assembly, such as foot plates, screws, nuts and bolt anchors, are included
- Load capacity labels in accordance with the German DGUV 208-061 specification
- Assembly instructions
- 5 Years warranty
Tyre racks are particularly practical for storing car tyres with or without rims. This complete tyre rack, with the dimensions 4,6 m x 40 cm x 2 m, consists of 3 levels. The number of bays is 2. Thanks to the modular design of our tyre racks, additional levels can be added and the width can be increased with extra bays of different lengths.
The load capacity of the tyre racks from TOPREGAL is 400 kg per level. The bay load, corresponding to the evenly distributed total load between 2 uprights, is 2.000 kg.
The tyres are stored on the orange stepped rack beams, which are hooked into the blue uprights using the simple plug-in system and secured against accidental lifting with locking pins. This design allows the beams to be individually adjusted in height in a grid of 50 mm. This increases the flexibility of use. The tyre rack can also be mounted to the wall using wall brackets. These are also available in our online shop. Stability is ensured by the robust rack uprights, each of which is anchored to the floor with 4 anchor bolts of size M8 x 55 mm.
The tyre rack is characterised by its attractive appearance and its durable, stable construction. All accessories, such as screws, nuts, locking pins and all required assembly material, are included.
-
ModelRR2000
-
Number of levels3
-
Rack layerWithout
-
Width4,600 mm
-
Depth400 mm
-
Height2,000 mm
-
Max. load per field2,000 kg
-
Maximum load per level400 kg
- 3 x tyre rack upright 2 m high / 40 cm deep, unit load capacity: 2.000 kg
- 12 x tyre rack beams 220 cm wide, compartment load capacity: 400 kg
- All material required for assembly, such as foot plates, screws, nuts and bolt anchors, are included
- Load capacity labels in accordance with the German DGUV 208-061 specification
- Assembly instructions
- 5 Years warranty
All data refer to evenly distributed loads. When loaded, the shelf load and field load must not be exceeded. In principle, the current guidelines on safety and health at work (german DGUV Rule 208-061) apply during use. TOPREGAL accepts no liability for accidents/damage caused by improper use. Our expert advisory team will be pleased to answer any questions you may have. Dimensions given are approximate and may deviate by a few centimetres. Contact us if you need the exact dimensions for your desired product.
